Garrett GT2871R - 836026-5021S ball bearing

Scope of Delivery:

- 836026-5021S

Technical Specifications:

- Fresh air housing 60A/R - Trim 48

- Turbine housing 64A/R - Trim 76

- Oil-cooled

- Water-cooled

- Double ball bearing

- Part No. 836026-5021S

- Up to 250-475HP

- Internal wastegate

Suitable for:

- Engines with a displacement from 1.8L to 3L

Description:

With us, you receive an original Garrett turbocharger. We source these directly from Garrett distributors, ensuring the authenticity of the turbos. Garrett is one of the few turbocharger manufacturers that subjects its turbos to several qualification tests, meaning you always get a top product. This includes a 1000-hour durability test on an engine in a Garrett Engineering Lab, thrust bearing test, checking the maximum tolerance of the bearing system, material fatigue, a vibration test, etc.

The Garrett GT and GTX series are all double ball bearing, finely balanced, and oil and water-cooled. There is also the older T series, which are mostly sleeve bearing. The GTX series differs from the standard GT in that it features a special, larger compressor wheel with more blades, leading to increased power and slightly better responsiveness. Its important for ball bearing turbos not to receive too much oil pressure. Therefore, an Oil Restrictor with a 0.9mm hole is used. A ball-bearing turbo responds approximately 400-500 RPM sooner than a sleeve bearing one. When selecting the right turbocharger, ask us or verify directly on the manufacturers website http://turbobygarrett.com/turbobygarrett/turbochargers. There, you can find all details such as exhaust housing options, product description, performance map, and drawings.
